high efficiency plastic tri-pak for packed tower scrubber

Name: high efficiency plastic tripak for packed tower scrubber
Brand: NKCHEM
Price: 150.00 USD

Quality high efficiency plastic tri-pak for packed tower scrubber wholesale

Brand Name : NKCHEM

Model Number : TP-0001

Certification : ISO

Place of Origin : CHINA

MOQ : 1 cubic metre

Price : $150.00 - $250.00/ cubic meter

Payment Terms : L/C, D/P, T/T, Western Union, paypal

Supply Ability : 3000 Cubic Meter/Cubic Meters per Year

Delivery Time : 10 days for one 20GP container

Packaging Details : woven bag

classification : tower packing

name : tri-packs

color : white

size : 25, 38, 50, 76, 90, 95mm

material : pp, pvc, pe, pvdf etc

application : water treatment, scrubbing, liquid extraction

Contact Now

Tri-Packs,Plastic Super Frame Ball

high efficiency plastic tri-pak for packed tower scrubber

Product advantages:

*high gas velocity, multiple blades and little resistance

*The character of high specific surface can well solve the exchange of gas and liquid.

*high productive power , low resistance and great turn-down ratio

Product description:

Plastic multi-aspect hollow ball is composed of two hemispheres which will form into a ball. And each hemisphere consists of a number of half fan-shaped leaves, the upper and lower leaves in a staggered arrangement. Its surface area is larger than other spherical fillers. It can be used in sewage treatment, desulfurization of CO2 in power plant, desulfuration and purified water tower packing. Plastic multi-aspect hollow ball is a new type of high-efficiency tower packing applied in water treatment equipment. The domestic power, chemical industry, papermaking and environmental protection industries have made use if in the equipments of desulfurization carbon and acid, oily-water separating, seawater desalination, purified and waste water treatment. The design concept is advanced and the structure is reasonable. This product has the virtue of light weight, wide free space, small wind resistance, and good surface hydrophilic, big full wet surface area and convenient filling in the equipment and sound usage effect.

Physical & chemical properties:

Item Material	PE	PP		RPP		PVC		CPVC		PVDF
Density g/m3	0.94~0.95	0.89~0.91		0.92~0.94		1.32~1.44		1.50~1.54		1.75~1.78
Working temperature	≤90	≤100		≤120		≤60		≤90		≤150
Compressive strength, N/mm	≥6.0	≥6.5		≥7.0		≥6.0		≥8.0		≥10.0
Chemical resistance	Yes		Yes		Yes		Yes		Yes		Yes

Main technical index:

Specification (mm)	Surface area (m²/m³)	Free volume (%)	Bulk density (kg/m³)	Number per m³
ø25	460	84	145	64000
ø38	325	87	125	25000
ø50	236	90	105	11500
ø76	150	92	90	3000

high efficiency plastic tri-pak for packed tower scrubber Images
